Display |
| Native Aspect Ratio: |
4x3 |
| Supported Aspect Ratio: |
4:3, 5:4, 16:9 |
| Brightness: (max ANSI lumens) |
Whisper: 3200 max ANSI lumens
High Bright: 4000 max ANSI lumens max ANSI lumens |
| Contrast Ratio: |
1000 : 1 Full On/Full Off |
| Display Technology: |
0.8" Poly-Silicon TFT LCD x 3, MLA |
| Data Compatibility: |
640 x 480, 800 x 600, 1024 x 768, 1280 x 1024, 1400 x 1050, 1600 x 1200 |
| Video Compatibility: |
Full NTSC, PAL, SECAM, 480i, 576i, 480p, 576p, 720p, 1080i |
| Color Wheel (DLP Only): |
No Color Wheel |
| Native Resolution: |
SVGA |
| Projector Placement: |
Ceiling Projection, Front Projection, Rear Projection |
| SMPTE Brightness: |
Not Available |
| Lamp Wattage: |
Whisper: Not Available
High Bright: 285 Watts |
| Lamp Life: |
Whisper: Not Available
High Bright: 2000 Hours |
| Minimum Image Size: |
2.5 ft (0.76 m) |
| Maximum Image Size: |
41.6 ft (12.68 m) |
| Standard Lens Zoom: |
1.2 : 1 |
| Standard Lens Throw Ratio: |
1.5-1.8:1 (Distance/Width) |
| Standard Lens Image Offset Ratio: |
9:1 to 1:1 |
| Standard Lens Projection Distance: |
3.75 - 62.4 ft (1.14 - 19.02 m) |
| Digital Keystone Correction (Vertical): |
+/-40° |
| Digital Keystone Correction (Horizontal): |
+/-20° |
| Lens Shift: |
Manual |
Inputs and Outputs |
| DVI: |
Number of Inputs: 1
Requires M1 to DVI cable |
| M1: |
Number of Inputs: 1
Supports DVI and VGA |
| HDMI: |
Number of Inputs: 1
Requires M1 to HDMI adapter |
| BNC: |
Not Available |
| Component (RCA): |
Number of Inputs: 1 |
| VESA (HD15): |
Number of Inputs: 1
Analog 15-pin |
| S-Video: |
Number of Inputs: 1
4-pin mini-DIN |
| Composite (RCA): |
Number of Inputs: 1 |
| Standard Definition TV: |
Composite RCA, S-Video, Component RCA |
| Enhanced Definition TV: |
Composite RCA, S-Video, Component RCA |
| High Definition TV: |
Composite RCA, S-Video, Component RCA, VGA, M1-DA |
| Computer: |
M1-DA, VGA |
| HDCP Support: |
No |
| Stereo RCA Jacks Inputs: |
Yes |
| Stereo 3.5 mm Mini-jack Inputs: |
Yes |
| 12v trigger for motorized screens (3.5 mm mini-jack): |
No |
| Projector Control: |
Projector Keypad, USB, RS-232, Remote, RJ45, 2.5mm Wired Remote |
| Speakers: |
2 x 3.0 watt stereo |
| Monitor Output: |
Yes |
| Audio Output: |
3.5mm audio out |
Compatibility |
| Data Compatibility: |
640 x 480, 800 x 600, 1024 x 768, 1280 x 1024, 1400 x 1050, 1600 x 1200 |
| H-Sync Range: |
15 - 91kHz |
| V-Sync Range: |
50 - 120Hz |
| Video Compatibility: |
Full NTSC, PAL, SECAM, 480i, 576i, 480p, 576p, 720p, 1080i |
General |
| Audible Noise: |
35 dB |
| Actual Dimensions: |
Height: 5.11 in (12.98 cm)
Length: 12.4 in (31.5 cm)
Width: 16.5 in (41.91 cm)
|
| Actual Weight: |
15.7 lbs (7.12 kg) |
| Shipping Dimensions: |
Height: 9.17 in (23.29 cm)
Length: 18.5 in (46.99 cm)
Width: 21.6 in (54.86 cm)
|
| Shipping Weight: |
23.2 lbs (10.52 kg) |
| Projector Warranty: |
2 years |
| Lamp Warranty: |
6 months |
| Accessories Warranty: |
90 days |
Operating temperature:
(at sea level) |
50 - 95° F (10 - 35° C) |
| Maximum Altitude Supported: |
7500 ft (2286 m) |
| Typical Power Consumption: |
400 Watts |
| Maximum Power Consumption: |
460 Watts |
| Power Supply: |
100 - 240 Volts at 50 - 60 Hz |
| Menu Languages: |
English, German, French, Italian, Spanish, Norwegian, Portuguese, Simplified Chinese |
| Approvals: |
UL and c-UL (US/Canada), FCC-A (US/Canada), CE (CE member countries), GOST (Russia), TUV GS (Germany), CCC (China), IRAM (Argentina), NOM (Mexico), C-Tick (Australia) |
